| Product name | Rod end Bearing |
| Material | Gcr15/Stainless steel/Bearing steel |
| Standard | ISO 9001 |
| Model | PHSA5/6/8/10/12/14/16/18/20/22/25/28/30 POSA5/6/8/10/12/14/16/18/20/22/25/28/30 |
| Service | OEM/ODM service |
| Delivery time | 5-10 days depends on quantity needed |
| Application: | Automotive.tractor.construction Machinery.rolling Mill |
Applications
Linear bearing is a kind of linear motion system, used for linear stroke and cylindrical shaft. Because the bearing ball is in contact with the bearing jacket, the ball rolls with the minimum friction resistance, so the linear bearing has small friction, is relatively stable, does not change with the bearing speed, and can obtain the smooth linear motion with high sensitivity and high accuracy. Linear bearing consumption also has its limitations, the most important is the bearing impact load capacity is poor, and the bearing capacity is also poor, followed by linear bearing vibration and noise at high speed. Linear bearing fast and easy automatic selection has been included. Linear bearings are widely used in precision machine tools, textile machinery, food packaging machinery, printing machinery and other industrial machinery sliding parts.
The structure of the spherical plain bearing is simpler than that of the rolling bearing. It is mainly composed of an inner ring with an outer spherical surface and an outer ring with an inner spherical surface.
Articulated bearings are generally used for low-speed swing movements (ie angular movements). Since the sliding surface is spherical, tilting movements (ie self-aligning movements) can also be performed within a certain angle range, and the support shaft and the shaft shell hole are not concentric When the degree is large, it can still work normally.
1, wear resistance bearing task, between the ring, rolling body and maintenance frame not only rolling friction, but also sliding friction, so that the bearing parts have been worn. In order to increase the wear of linear bearing parts, maintain bearing accuracy stability, extend service life, bearing steel should have good wear resistance.
2. Hardness Hardness is one of the most important qualities of bearing quality, which has an indirect impact on contact fatigue strength, wear resistance and elastic limit. The hardness of bearing steel in use should individually reach HRC61~65, which enables the bearing to achieve higher contact fatigue strength and wear resistance.
3, antirust performance in order to avoid bearing parts and finished products in the process of processing, storage and application of corrosion rust, the bearing steel should have good antirust performance.
4, processing performance bearing parts in the consumption process, to go through many cold, hot processing procedures, in order to satisfy the request of a small amount, high efficiency, high quality, bearing steel should have good processing performance.
Structural characteristics and working principle
1.Overall structure: PHSA bearing is an assembly of joint bearing and rod end. The rod end processing has internal thread, easy to connect with other components installation. Inside the bearing body is a spherical sliding pair consisting of an outer ring with an inner sphere and an inner ring with an outer sphere (or similar structure).
2.Core components and Materials:
Rod end body: usually made of S35C carbon structural steel and other materials, and after chromate plating treatment, with good strength and corrosion resistance.
Sliding contact surface: Depending on the type, the sliding surface may use special copper alloy bushing, special zinc alloy die casting, or special PTFE (polytetrafluoethylene) lining with self-lubricating properties. Copper alloy bushing has good running-in property, excellent wear resistance and load resistance; However, PTFE lining is suitable for self-lubricating conditions.
3.Working principle: The spherical sliding structure enables the inner ring to tilt and rotate at a certain Angle in the outer ring. This automatic self-aligning ability can compensate for the misalignment problem caused by installation error, axis bending and so on, and ensure the smooth movement of the mechanism.
