| Product name | Rod end Bearing |
| Material | Gcr15/Stainless steel/Bearing steel |
| Standard | ISO 9001 |
| Model | PHSA5/6/8/10/12/14/16/18/20/22/25/28/30 POSA5/6/8/10/12/14/16/18/20/22/25/28/30 |
| Service | OEM/ODM service |
| Delivery time | 5-10 days depends on quantity needed |
| Application: | Automotive.tractor.construction Machinery.rolling Mill |
Applications
PHSA rod end bearing is a rod end joint bearing with internal thread, which is usually composed of two parts: the bearing body (joint bearing) and the rod end with thread. It can achieve multi-direction swing and rotation, is the key component connecting components and transfer power and motion, especially suitable for the need to bear composite load and Angle centering of mechanical parts.
PHSA series rod end joint bearing (commonly known as fisheye bearing) is a kind of high precision universal connector, using internal thread design (M5-M30 specification), suitable for multi-angle adjustment of mechanical transmission system. Its core structure is composed of hardened steel ball head and self-lubricating bushing, which has the characteristics of wear resistance and impact resistance.
1, wear resistance bearing task, between the ring, rolling body and maintenance frame not only rolling friction, but also sliding friction, so that the bearing parts have been worn. In order to increase the wear of linear bearing parts, maintain bearing accuracy stability, extend service life, bearing steel should have good wear resistance.
2. Hardness Hardness is one of the most important qualities of bearing quality, which has an indirect impact on contact fatigue strength, wear resistance and elastic limit. The hardness of bearing steel in use should individually reach HRC61~65, which enables the bearing to achieve higher contact fatigue strength and wear resistance.
3, antirust performance in order to avoid bearing parts and finished products in the process of processing, storage and application of corrosion rust, the bearing steel should have good antirust performance.
4, processing performance bearing parts in the consumption process, to go through many cold, hot processing procedures, in order to satisfy the request of a small amount, high efficiency, high quality, bearing steel should have good processing performance.
Structural characteristics and working principle
1.Overall structure: PHSA bearing is an assembly of joint bearing and rod end. The rod end processing has internal thread, easy to connect with other components installation. Inside the bearing body is a spherical sliding pair consisting of an outer ring with an inner sphere and an inner ring with an outer sphere (or similar structure).
2.Core components and Materials:
Rod end body: usually made of S35C carbon structural steel and other materials, and after chromate plating treatment, with good strength and corrosion resistance.
Sliding contact surface: Depending on the type, the sliding surface may use special copper alloy bushing, special zinc alloy die casting, or special PTFE (polytetrafluoethylene) lining with self-lubricating properties. Copper alloy bushing has good running-in property, excellent wear resistance and load resistance; However, PTFE lining is suitable for self-lubricating conditions.
3.Working principle: The spherical sliding structure enables the inner ring to tilt and rotate at a certain Angle in the outer ring. This automatic self-aligning ability can compensate for the misalignment problem caused by installation error, axis bending and so on, and ensure the smooth movement of the mechanism.
Use and maintenance advice
1.Installation: Ensure that the installation hole is well aligned with the bearing rod to avoid initial load bias caused by forced installation. When tightening, use appropriate tools and do not overexert yourself.
2.Lubrication: For non-self-lubricating models, regular lubrication should be performed according to the period and grease type recommended by the manufacturer.
3.Insection: Check the bearing regularly for signs of abnormal loosening, wear or corrosion. If it is found that the spherical clearance is too large or the rotation is not smooth, it should be replaced in time.
PHSA rod end bearing is a kind of mechanical foundation part with important function and strong adaptability. Its self-aligning capability and various lubrication options allow it to operate stably under complex operating conditions. I hope this detailed introduction will help you to choose the right PHSA bearing for your project.
If you have specific use cases or further questions on a specific detail (e.g. more detailed dimensions for a model), feel free to ask and I'll be happy to provide more in-depth information.
